Chameleon for Revit. Yesterday I released a new version of Chameleon for Revit with some exciting new features, including tools to create and edit multiple curtain grid systems on a single curtain wall. Image Upload Bug Fixed! All our free hatching files are fully compatible with AutoCAD and AutoCAD LT in addition the PAT files are also compatible as Autodesk Revit Hatch Patterns for filled regions. The library includes free Autodesk compatible wood patterns, free stone hatches, brick hatch patterns, geometric patterns seamless textures and many scales of each design.

Publisher:
3DiQ
File size:
24.8 MB
Date added:
Jul 25, 2019 Last update check: 1 minute ago
Licence:
Trial Buy Now
Runs on:
Revit 2017 / 2018 / 2019 / 2020

The free PAT files are Autodesk Revit Architecture compatible The CAD library includes free Autodesk Revit wood pattern files, free stone hatches, brick hatch patterns, geometric patterns and many scales of each design. Wood CAD Hatch Patterns. I can't seem to be able to figure out the syntax / code for creating what I believe is referred to as '1/3 Staggered Running Bond' pattern for a 12' x 24' tile. If that is not the correct terminology, please correct me. Chameleon for Revit. Yesterday I released a new version of Chameleon for Revit with some exciting new features, including tools to create and edit multiple curtain grid systems on a single curtain wall. Image Upload Bug Fixed!

Download Latest Version
(24.8 MB)

Masonry iQ for Revit adds support for masonry products in Autodesk® Revit® with custom bond patterns, properly bonded layout, bond beams, masonry sections and other tools. It allows users to create masonry specific wall type families with additional properties.

Masonry iQ walls will generate custom PAT files in elevation, sections that show true masonry coursing and sweeps at bond beam locations. PAT files and sections can be purged to manage file size.

/marvel-mugen-download.html. The Analyze Bond tool will calculate the proper layout based on the assigned bond pattern and may take some time to generate on large jobs. Non-modular walls will show a bond cut icon where field cuts will be required to maintain bonding at corners. These icons can be moved by dragging them to a new location if the bond cuts will remain in the design. Ideally, the wall lengths will be adjusted to eliminate the cuts and create a modular design.

Revit Brick Pat File

Use the standard join options in Revit at Masonry iQ wall corners to modify the bond type at corners. Corners that are not 90 degrees cannot be mechanically bonded and default to miter, though they can be changed to squared off. Material schemas can be mapped to bond patterns using images from participating manufacturers. These schemas can be used to render masonry on a model in Revit or other applications.

Files

Features:

  • Study Modularity
  • Properly Bonded Corners
  • See Cuts at Openings
  • Custom Masonry Patterns
  • Generate Sweeps
  • Draw Masonry Sections

What’s new in version 19.17.0.1:

Free Pat Files For Revit City Free

Revit
  • Fixed bugs related to Revit 2017 install.

What’s new in version 19.16.0.1:

  • Updated Release with bug fixes
  • Performance improvements
  • Supported Revit 2020
  • Added more Material Images

About 3DiQ

We make Masonry Design Software for Revit. Our first product is called Masonry iQ and it helps Architects create compelling, realistic 3D renderings.

Gallery

Free Pat Files For Revit City Of Los Angeles


Overview of the features including custom bond patterns, automated masonry sections, bond beams and layout analysis.
Tom Cuneio, President of 3DiQ, Talks About His Product called MasonryiQ, A Revit Plugin That Amplifies the Creative Power of Revit for Masonry.
Non-modular layouts show required cuts. These cuts can either be relocated or layout can be adjusted to eliminate cuts.
Squared off corner with proper bonding calculated. Miter and mechanical bond are optional corner types.
Create a masonry materials schema.
Screen shot of Masonry iQ
Browse local producers.
Masonry wall sections drawn by Masonry iQ.
The wall type UI in Masonry iQ shows masonry wall properties including corner bonding.
Development of custom bond patterns in the Masonry iQ UI.
Render masonry schemas in your Revit model.
Setting of bond beams that generate sweeps.


Latest Version

Masonry iQ for Revit 19.17.0.1

Pat Files For Revit

Old Versions

Free Revit Files

Need new hatch patterns for Revit?

11/11/2018

Hatch patterns are incredibly useful graphics that communicate that materials used on your drawings. Like Autocad, Revit Architecture comes with a handful of hatch patterns. Called 'Filled Patterns' in Revit, these can be found under the Manage tab, Additional Settings and Fill Patterns. These patterns come with two types: Drafting and Model. 'Drafting' patterns are most often used for cross sections. These types of patterns do not have a size and change depending on scale being used in the Revit view. 'Model' patterns are typically used for surfaces, therefore appear on plans and elevations. It won't take long for you to outgrow the fill patterns available in Revit. You will then have the choice of creating additional patterns and/or uploading new patterns into Revit. Follow these steps to get your started:
  1. Custom Hatch Patterns
    1. If unable to find an appropriate hatch pattern for your materials in Revit, users can create their own with Manage tab / Materials
    2. The Graphics tab of the Materials Browser contains parameters for Surface Pattern which control hatch patterns in Revit. Two levels of hatch can be added to your elements:
      1. Surface Pattern / Foreground (choose pattern and color)
      2. Surface Pattern / Background (choose pattern and color)
      3. If Surface Pattern / Foreground / Pattern = Solid (using a Drafting not Model pattern), then this will be the only pattern that appears
  1. When a pattern is chosen, users can either select Drafting (used for sections) or Model (used for plans, elevations, RCP, etc.) patterns.
  2. Use the following steps to create simple hatch patterns within Revit
    1. Select new hatch at bottom of Fill Patterns menu
    2. Use Basic option in menu provided to create a pattern, create a new pattern name and choose OK
    3. Use Custom option and browse button load a .pat (see pattern files below). If the .pat file contains multiple hatch patterns, choose a single pattern from the list provided. Adjust the import scale as needed (i.e. try values of 1, 10, 100, etc.). When complete, create a new pattern name and choose OK
  3. An alternative to loading fill patterns is to copy the fill pattern from another currently open Revit file.
    1. Open new project and Revit file containing pattern required
    2. Within the new project, use Manage / Transfer Project Standards, Copy from=name of Revit file with patterns, choose Check None, select Fill Patterns from list provided and choose OK. This option will copy all patterns from source file.
    3. Another method is to apply the hatch pattern to an element in the source file (i.e. small floor area) and copy/paste this element into your new file. Only the single pattern will be copied into your new Revit file.
  4. Pattern files (.pat) format for Revit
    1. Pattern files (.pat) must be correctly formatted to work within Revit
    2. Open the pattern file(select, right-click and choose Edit with Notepad…)
    3. Each block of code must start with either of the following:
      1. * (followed by the name of the hatch and a description)
      2. ;%TYPE=Model or Drafting (depending on which type of hatch is required in Revit)
      3. The remainder is programming required to create the hatch pattern (do not change)
      4. Modify the file as needed and Save the file​​​
  5. Modify the file as needed and Save the file
  6. Here are a series of useful websites that I have found:
  7. Useful sites with pattern files:
    1. Cadhatch
      1. http://www.cadhatch.com/free-downloads/4588167679
    2. Mica Stonworks
      1. http://micastoneworks.com/resources/hatch-patterns/
    3. Custom Hatch
      1. https://revitiq.com/custom-revit-hatch-patterns/
    4. Stone hatch and images
      1. https://harristone.com/download/
    5. RevitCity
      1. https://www.revitcity.com/downloads.php?action=viewrevit&revit_l1_id=26&revit_l2_id=0&revit_l3_id=0&start=180
    6. Revit File Download w/ patterns
      1. https://www.revitcity.com/downloads.php?action=view&object_id=19609
    7. Best patterns / Culturedstone.com
      1. https://www.culturedstone.com/resources/architect-resources/cad-resources
